SC1210 Metal Hammer Mill

Application areas:

Metal Chips Scrap Steel Raw Aluminum Hardware Scrap Home Appliances Cooked Aluminum

Product Introduction

SC1210 crusher is mainly used to treat waste metal aluminum. Sc1210 waste aluminum crusher can crush and process large-size solid metal materials, so as to achieve the equipment that meets the size. The fast operation of the sc1210 crusher hammer makes the crushed aluminum rotate with the hammer, and after a short time of beating and rubbing, the formed particles flow out of the screen at the bottom of the equipment. The materials that do not meet the specifications are retained in the crushing bin and continue to be crushed until they meet the size of the screen hole, so as to ensure the consistency of the discharge specifications.

%e9%a6%96%e5%9b%be01-25
%e9%a6%96%e5%9b%be02-26

A metal crusher, also known as a metal pulverizer, is a machine specifically designed for crushing scrap metal materials. It uses the basic principle of a motor to drive a fan wheel to squeeze, and its core is to use a hammer to strike. Under the drive of a high-speed and high torque motor, the hammer heads on the main rotor take turns hitting the object to be crushed that enters the chamber. Through the space formed between the lining plate and the hammer heads, the object to be crushed is torn into the required specifications.

%e9%a6%96%e5%9b%be03-26
%e9%a6%96%e5%9b%be04-25

Product advantages

  • 1.Wide feeding port and large crushing cavity

    With wide feeding port and large crushing cavity, it is applicable to raw materials with large crushing volume. The heavy rotor design scheme ensures high-quality rotors with its rigorous production and processing methods.

  • 2.Greatly improve the axial compressive strength of machinery and equipment

    The bearing with seat is forged by steel casting, which greatly improves the axial compressive strength of the machine and equipment. It is equipped with a hydraulic transmission system and built-in top opening equipment, which can quickly overhaul and maintain the machine and equipment and reduce the shutdown time.

  • 3.Compact structure and strong equipment rigidity

    It is equipped with magnetic separation equipment and adopts a strong magnetic drum separator to separate the non-ferrous gold and iron metals contained in the materials. It has a compact structure, strong equipment stiffness, and the rotor has greater rotating inertia force, so it can be manufactured faster.

Technical Parameter

Model Power(kW) Feed size(mm) Average capacity(t/h)
SC6050 22-37 600×800 0.3-0.5
SC7080 37-55 600×760 0.8-1
SC8010 55-75 1000×800 0.3-0.5
SC1280 75-200 1000×1200 1.5-2.5
SC1210 132-200 1200×650 3-6
SC1214 200-315 600×1200 0.3-0.5
SC1415 55-75 1000×800 0.3-0.5
SC1680 132-200 1300×1500 3-5
SC1690 132-315 1000×900 5-6
SC1614 450-560 900×1660 750
