VSC4-1000 Vertical Hammer Crusher

Application areas:

Radiator;Motor rotor;UBC bale;Aluminium profiles;Engine block;Glass;Weee;Scrap steel

Product Introduction

The VSC4-1000 Vertical Hammer Crusher is a robust and efficient machine used in the recycling of waste metals, such as scrap steel, aluminum, copper, and other metals. It uses a combination of high-speed rotating hammers and vertical shaft technology to crush the metal scrap into smaller particles. This makes the material easier to handle, transport, and further process for various industrial applications.

%e9%a6%96%e5%9b%be01-16
%e9%a6%96%e5%9b%be02-16

TheVSC4-1000 Vertical Hammer Crusher operates by feeding scrap metal into the crushing chamber, where high-speed rotating hammers strike the material. The material is then shattered into smaller pieces and exits the crusher directly, ready for further processing, such as sorting or smelting.

%e9%a6%96%e5%9b%be03-16
%e9%a6%96%e5%9b%be04-16

Product advantages

  • 1.Vertical Design

    The vertical configuration helps to reduce floor space requirements while improving processing efficiency.

  • 2.High Efficiency

    The hammer crusher uses high-speed rotating hammers to impact and crush scrap metal, effectively breaking down large pieces into smaller, uniformly sized particles.

  • 3.Durability

    Made from high-quality materials, the crusher is designed to handle tough materials and maintain performance over long periods of operation.

  • 4.Energy Saving

  • The design ensures low energy consumption while maximizing output, making it a cost-effective solution for metal recycling.
  • 5.Wide Application

  • It can process a variety of metal waste, including automobile scrap, household appliances, and industrial scrap, making it versatile for different recycling needs.
  • 6.Easy Maintenance

  • The machine is designed for ease of maintenance, with quick access to parts that require regular servicing or replacement.

Technical Parameter

Model Power(Kw) Feeding hopper size(mm) Cylinder diameter(mm) Dimension(mm)
VSC4-1000 75-110 1000X1000 1000 3530X1370X3900
VSC4-1200 110-200 1100X1200 1200 3300X4300X5100
VSC4-1600 250-315 1100X1600 1600 4400X2300X6000
